BS 88 Ref. List Ref Current Rating In Amps (A) Fixing Centres
(Inches) (mm)
(Overall Length)
- BINS 2,4,6,10,16,20,25,32 2 3/8 60
A1 BINIT 2,4,6,10,16,20,25,32 1 3/4 44.5
A2 BITIA 2,4,6,10,16,20,25,32 2 7/8 73
A3 BITIS 32,35,40,50,63 2 7/8 73
A4 BITCP 32,40,50,63,80,100 3 11/16 94
- BITFP 160,200 3 11/16 94
- BITBC 2,4,6,10,16,20,25,32,40,50,63 4 3/8 111
B1 BITC 80,100 4 3/8 111
B2 BITF 125,160,200 4 3/8 111
B3 BITKF 250,315 4 3/8 111
B4 BITMF 355,400 4 3/8 111
- BITKM 250,315 4 3/8 111
C1 BITM 355,400 5 1/4, 7 1/4 133, 184
C2 BITTM 450,500,560,630 5 1/4, 7 1/4 133, 184


  BINS   BINIT, BITIS   BITIA, BITCP, BITFP, BITBC


  BITC, BITF, BITKF,BITMF,BITKM   BITM / BITTM
